Gossen Metrawatt METRAHIT ENERGY

Datalogger and IR-interface, Incl. ISO17025 Calibration

The new, professional METRAHIT ENERGY multimeter is exceeding all previous performance limits. Thanks to simultaneous TRMS current and voltage measurement (AC, AC+DC and DC) with a resolution of 60,000 digits, all important power quantities can be precisely acquired.

Order #: METRAHIT ENERGY

Mfg Part #: M249A

$1,053.00 USD



Usually ships in 7-10 days

Free shipping over $250

New Purchase Calibration Learn More

Save time and money by calibrating your new instrument before it leaves our warehouse, ensuring it arrives ready to be put into service. Find out how.

Add a Calibration to Your Item

Add Items to Cart

Request a Calibration Quote

Transcat can calibrate your existing instruments.

Request a Calibration Quote

Rent From Transcat

Do you need a test instrument for a short time?

Request a Rental Quote

click on image to view gallery image(s)

View All Gossen Metrawatt Products

Overview :

Product Highlights

  • RMS measurement with the following and more: V AC TRMS, V AC+DC TRMS 100 kHz with bandwidth, V DC, dB, Hz (V), Hz (A), Ω, µF, V diode, °C / F (TC / RTD)
  • Power measurement (W, VAr, VA, PF): active, reactive and apparent power with extreme values, power factor
  • Energy measurement (Wh, VArh, VAh) active, reactive and apparent energy, mean power value with adjustable observation period and maximum value
  • Mains quality analysis: recording of over and undervoltage, dips, swells, voltage peaks and transients in 0, 50 and 60 Hz systems
  • Harmonic analysis: RMS values and distortion components up to the 15th harmonic at 16.7, 50, 60 and 400 Hz

Special measuring functions:

  • Crest factor (CF), conductivity (nS), low impedance (RSL), duty cycle (%), cable length (km)
  • Triple display, display illumination can be activated for difficult lighting conditions
  • Resolution: 60,000 digits (4 6/7 place)
  • 1 kHz / -3 dB low-pass filter can be activated
  • Direct current measurement from 10 nA to 10 A, 16 A intermittently
  • current measurement with current clamp transformers and sensors, transformation ratio is taken into account at the display
  • Measurement data memory for up to 300,000 measured values
  • Instrument is fully remote controllable without activating the rotary switch or changing current sockets

Each Unit Includes

  • 1 multimeter
  • 1 pair of safety measurement cables (1.5 m) with 4 mm test probes, 1000 V CAT III, 600 V CAT IV (KS17-2)
  • 2 batteries, 1.5 V, type AA
  • 1 condensed operating instructions, English/German
  • 1 CD ROM, content: operating instructions in English and German)
  • 1 DAkkS calibration certificate
