Used Tektronix CR286A BERTScope Clock Recovery Instrument, 28.6Gb/s

Product Highlights

Features:

• 100 mV
• 12 MHz
• 28.6 Gb/s
• Instrumentation quality clock recovery
• Accurate, variable loop bandwidth from 100 kHz to 12 MHz, with optional 24 MHz for the jitter transfer function (JTF) bandwidths of USB 3.0, SATA 6G, and PCIe Gen3
• Accurate, adjustable, self-measured, and displayed PLL loop bandwidth, peaking, and JTF - get the "Golden PLL" response needed for standards compliance testing
• Programmable peaking adjustment with first- and second-order roll-off capability
• USB control interface integrated into BERTScope view, or stand-alone with included BERTScope PC software
• DC-coupled data through path for accurate signal integrity
• Full and divided clock outputs with selectable divide ratios. Full-rate clock output up to 14.3 Gb/s
• Built-in equalizer function enables clock recovery under high ISI input conditions
• Data measurement capability

Applications:

• Design/Verification of high-speed I/O components and systems
• Signal integrity analysis
• Certification testing of serial data streams for industry standards

The Tektronix CR286A is an analyzer.
