Amplifier, AC/DC Current Probe DC to 100 MHz

Rent instruments from Transcat - Weekly and monthly rentals available. Weekly and monthly rentals available.
Request a Quote today!

Order #: TCPA 300-RENT2

Mfg Part #: TCPA 300

$75.00 USD

Usually ships in 7-10 days

Free shipping over $250

Add Items to Cart

Request a Calibration Quote

Transcat can calibrate your existing instruments.

Request a Calibration Quote

Rent From Transcat

Do you need a test instrument for a short time?

Request a Rental Quote

click on image to view gallery image(s)

Overview :

Tektronix TCPA 300 Highlights

The TCPA300 from Tektronix is a current probe amplifier. This amplifier when used with TCP312A, TCP305A and TCP303 probes, provides a wide range of current measurement capability and spans the gap between low level milliamp measurements to very high current levels. These three probes provide current measurement capabilities of 30A, 50A and 150A DC continuous and for even higher current levels. Higher frequency performance is available with TCP312A providing greater than or equal to 100MHz bandwidth and maximum current of 30A DC. The TCPA300 is approved by UL3111-1 first edition, CAN/CSA C22.2 number 1010.1-92, EN61010-1:2001, EC Council Directive 89/336/EEC, FCC Part 15, Subpart B class A and AS/NZS 2064.1/2 standards.

  • DC to 100MHz maximum bandwidth
  • Automatic control and onscreen scaling and units
  • AC/DC input coupling
  • Low insertion impedance reduces device under test loading
  • Split core construction allows easy circuit connection
  • Status indicators provide visual operating status and notification of potential error conditions
  • Low DC drift and noise allows improved low level current measurements
  • Rise time is less than or equal to 23ns
  • Lowest measurable current at ±3%accuracy is 5mA
  • Operating temperature range from 0°C to 50°C
  • Requires TCP305 or TCP312 or TCP303 Probes
