Micrometers

Micrometers

Digital Micrometer Standard



Our metrology solutions include mechanical and digital micrometers that accurately measure short distances, thicknesses or diameters. A standard instrument features a semicircular frame with an anvil on one end and a barrel with a spindle and turning thimble on the other. When the spindle and anvil make contact with an object, measurements are read from scales and computed, or the total measurement is digitally displayed. An outside micrometer often measures wires and shafts, an inside type measures hole diameters, and a depth meter measures slots. Precision electronic micrometers feature LCD displays and an output port for transmissions. Essential micrometer standards can be used to check micrometers and make gage comparisons. We’re your premier provider of micrometers, standards, and depth gages from tool innovators, such as Starrett, Mitutoyo, and Ametek Chatillon.



Choosing the Right Micrometer Type



Transcat has most every type of micrometer, including outside, inside, depth, and screw thread. These tools are available in caliper, tube, rod, and electronic formats. Micrometer designs are based on their functions. A blade-type meter works for groove and slot measurements, while a screw-thread micrometer can determine pitch diameter. Depth micrometer sets can include rods in various lengths for determining a scope of measurements. When choosing a digital micrometer, reviewable specifications can cover: range, resolution, accuracy, contacts, force, mass, and environment compatibility.



Handheld Micrometers and Standards



A handheld micrometer from Mitutoyo supports highly accurate measurements. The instruments include a rotary sensor, rigid frame, contact pressure mechanism, and precision thread spindle. Micrometer standards from this maker are indispensable tools, available in various lengths and diameters. The Starrett depth micrometers feature a ratchet stop, while the brand’s electronic micrometers are built to deliver uniform pressure.



Buy Calibrated Micrometers Only from Transcat



Because Transcat operates dozens of ISO 17025 Accredited Calibration Labs across the United States and Canada, we are uniquely positioned to offer new instrument calibration services on most of the items we distribute.  If your quality system requires that your instruments have a valid calibration certificate at all times, take advantage of our micrometers calibration capabilities so that your instrument arrives ready to be put into use.



Our dimensional measurement products include many micrometer types. To learn more, start a Live Chat or call 800.828.1470 today.







Read More

Compare up to 5 Items

You have no items to compare.

List Grid

Items 1-25 of 1451

Set Ascending Direction
Page:
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5
  1. Mitutoyo 293-130

    Micrometer, Sub-Micron Digital 0-1"

    Order #: 293-130

    Mfg #: 293-130

    Usually ships in 7-10 days

    $1,630.00 USD

    $1,548.50 USD

  2. Starrett 128CZ 64377

    Inside Micrometer Set

    Order #: 128CZ

    Mfg #: 64377

    Usually ships in 7-10 days

    $4,956.00 USD
  3. Mitutoyo 547-400S

    Mitutoyo Thickness Gage,Digital 0-.470"/0-12mm

    Order #: 547-400S

    Mfg #: 547-400S

    Usually ships in 7-10 days

    $831.00 USD

    $789.45 USD

  4. Starrett 128BZ 64376

    Inside Micrometer Set

    Order #: 128BZ

    Mfg #: 64376

    Usually ships in 7-10 days

    $3,535.00 USD
  5. Starrett S436DXRLZ 64463

    6-12" Outside Micrometer Set

    Order #: S436DXRLZ

    Mfg #: 64463

    In stock

    $2,524.00 USD
  6. Mitutoyo 164-164

    Digital Micrometer Head

    Order #: 164-164

    Mfg #: 164-164

    In stock

    $919.00 USD

    $873.05 USD

  7. Mitutoyo 104-147A

    800-900mm Outside Micrometer

    Order #: 104-147A

    Mfg #: 104-147A

    Usually ships in 7-10 days

    $1,440.00 USD

    $1,368.00 USD

  8. Starrett 445AZ-12RL 67117

    0-12" Micrometer Depth Gage

    Order #: 445AZ-12RL

    Mfg #: 67117

    Usually ships in 7-10 days

    $512.00 USD
  9. Starrett 445BZ-12RL 67118

    Micrometer Depth Gages, 0-12"

    Order #: 445BZ-12RL

    Mfg #: 67118

    Usually ships in 7-10 days

    $533.00 USD
  10. Mitutoyo 104-146A

    Outside Micrometer 700-800MM

    Order #: 104-146A

    Mfg #: 104-146A

    Usually ships in 7-10 days

    $1,320.00 USD

    $1,254.00 USD

  11. Mitutoyo 337-304

    Digimatic Tubular Inside Micrometer IMZ-60"MJ

    Order #: 337-304

    Mfg #: 337-304

    Usually ships in 7-10 days

    $1,290.00 USD

    $1,225.50 USD

  12. Starrett S436.1CXRLZ 68044

    0-6" Outside Micrometer Set

    Order #: S436.1CXRLZ

    Mfg #: 68044

    Usually ships in 7-10 days

    $1,416.00 USD
  13. Starrett 3732XFL-1

    English/Metric Electronic Micro

    Order #: 3732XFL-1

    Mfg #: 12268

    Usually ships in 3-5 days

    $140.00 USD
  14. Mitutoyo 137-201

    Extension Rod, 50-150mm

    Order #: 137-201

    Mfg #: 137-201

    Usually ships in 7-10 days

    $221.00 USD

    $209.95 USD

  15. Mitutoyo 326-352

    Digital Screw Thread Micrometer

    Order #: 326-352

    Mfg #: 326-352-30

    Usually ships in 7-10 days

    $705.00 USD

    $669.75 USD

  16. Starrett 440Z-6L 52117

    Micrometer Depth Gages, 0-6"

    Order #: 440Z-6L

    Mfg #: 52117

    Usually ships in 7-10 days

    $297.00 USD
  17. Mitutoyo 510-132

    Indicating Micrometer 1-2in

    Order #: 510-132

    Mfg #: 510-132

    Usually ships in 7-10 days

    $913.00 USD

    $867.35 USD

  18. Mitutoyo 227-211

    0-.60" Digimatic Absolute Micrometer

    Order #: 227-211

    Mfg #: 227-211

    Usually ships in 7-10 days

    $855.00 USD

    $812.25 USD

  19. Starrett 124MBZ 56142

    Solid-Rod Inside Micrometer Set

    Order #: 124MBZ

    Mfg #: 56142

    Usually ships in 7-10 days

    $318.00 USD
  20. Mitutoyo 293-330-30

    0-1"/0-25.4mm Micrometer,w/SPC Ratchet Stop, Digital

    Order #: 293-330-30

    Mfg #: 293-330-30

    Usually ships in 7-10 days

    $240.00 USD

    $228.00 USD

  21. Starrett 440Z-3L 52113

    Micrometer Depth Gages, 0-3" Ra

    Order #: 440Z-3L

    Mfg #: 52113

    Usually ships in 7-10 days

    $249.00 USD
  22. Mitutoyo 329-250-10

    0-150mm Digital Metric Depth Micrometer

    Order #: 329-250-10

    Mfg #: 329-250-10

    Usually ships in 7-10 days

    $590.00 USD

    $560.50 USD

  23. Starrett 790AFL-1 64048

    Digital Multi-Anvil Micrometer 0-1"

    Order #: 790AFL-1

    Mfg #: 64048

    Usually ships in 7-10 days

    $693.00 USD
  24. Starrett 78XTZ-625 68132

    Inside Micrometer 1/2-5/8"

    Order #: 78XTZ-625

    Mfg #: 68132

    Usually ships in 7-10 days

    $652.00 USD
  25. Starrett 795.1XFL-1

    0-1" Digital Micrometer

    Order #: 795.1XFL-1

    Mfg #: 01100

    In stock

    $256.00 USD
