Fluke 789 Process Meter, DMM & Loop Calibrator

Order # 789E | Mfg # 1633984

In Stock!

Fluke 789 Process Meter, DMM & Loop Calibrator

$1,389.14

In stock

Ships Free Over $100

Tariff fees or manufacture imposed surcharges may be applicable.

Overview

Product Highlights

24 V loop power supply
HART mode setting with loop power (adds 250 ohm resistor)
100% larger dual display
1200 ohm drive capability on mA source
Enhanced backlight with two brightness settings
Improved battery power with four AA batteries
0-100% mA Span Check buttons to toggle between 4 and 20 mA
Infrared I/O serial port compatible with FlukeView Forms
V 2.1 Software (available Feb. 2003)
5 V dc measurement capability on the 4 V dc range for precise 1-5 V measurements
Externally accessible fuses for easy replacement
DMM designed to meet 1000 V IEC 1010 Cat III standards
Precision 1000 V, 440 mA digital multimeter
Measure ac and dc volts
AC and dc voltage accuracy: 0.05 % dc current accuracy, 1 uA resolution to 30 mA
Simultaneous mA and % of scale readout
True-rms ac voltage measurement
Frequency measurement to 20 kHz
Min/Max/Average/Hold/Relative modes
Diode Test and Continuity Beeper
20 mA dc current source / loop calibrator / simulator
Simultaneous mA and % of scale readout
Manual Step (100 %, 25 %, Coarse, Fine) plus Auto Step and Auto Ramp
Externally accessible battery for easy battery changes V overload protection on V, ohms, frequency, mA (backed-up by 440 mA 1000 V fuse)
Process Meter
Does Not Include calibration certificate

Each Unit Includes

TL71 Premium Test Lead Set
AC72 Alligator Clips
Four AA alkaline batteries (installed)
Users Manual
Quick Reference Guide

Technical Resources

Application - Troubleshooting Power Harmonics
Application - Who Sets the Rules for Electrical Testing and Safety
Application - ABCs of Multimeter Safety: Multimeter Safety and You
Application - Fluke Connect™ ABCs of DMMs
Brochure - 7 Reasons to Connect Your Tools
Brochure - Fluke Connect™
Brochure - Oil and Gas Downstream
Brochure - Oil and Gas Midstream
Fluke 789 ProcessMeter™ - User's Manual
Fluke 789 ProcessMeter™ - Calibration Manual
Fluke 789 ProcessMeter™ - Quick Reference Guide
Fluke 789 ProcessMeter™ - Safety Sheet
Fluke 789 ProcessMeter™ - Safety Sheet Supplement
Fluke 789 ProcessMeter™ - CE Declaration of Conformity
Fluke 789 ProcessMeter™ - CSA Certificate of Conformity
Fluke 789 ProcessMeter™ - EMC Certificate of Conformity
Fluke 789 ProcessMeter™ - TUV SUD Certificate of Conformity
Fluke 787 / 789 ProcessMeter™ - Statement of Memory Volatility
Application - Fluke ProcessMeter Proves that Less can be More
Application - In-field Valve Positioner Checks Using the Fluke 789 ProcessMeter
Brochure - Fluke 789 ProcessMeter™

Specifications

Current measurement	Range	0-1 A AC or DC
	Resolution	1 mA
	Accuracy	0.2% + 2 LSD (DC)
	Range	0-30 mA
	Resolution	0.001 mA
	Accuracy	0.05% + 2 lSD
Current sourcing	Range	0-20 mA or 4-20 mA
	Resolution	0.05% of span
	Drive capability	24 V Compliance or 1200 Ω @ 20 mA
Frequency	to 19.999 kHz, 0.005% + 1 LSD
Continuity	Beeps for resistance < 100 Ω
Voltage measurement	Range	0-1000 V AC (true-rms) or DC
	Resolution	0.1 mV to 1.0 V
	Accuracy	0.1% Rdg + 1 LSD (VDC)
Resistance measurement	to 40 MΩ, 0.2% + 1 LSD
Diode test	2.0 V shoes diode voltage drop
Display current and % of span	Yes
Auto Step, Auto Ramp	Yes
Environmental Specifications
Operating temperature	-20°C to 55°C
Storage temperature	-40°C to 60°C
Humidity (without condensation)	95% up to 30°C
