Order #: ADT875
Mfg #: ADT875
Additel ADT875
Order #: ADT875
Mfg #: ADT875
Currently a configured instrument on this page is sold at list price. Add to quote to receive your Transcat customer pricing.
Product Highlights
- Temperature range
- -40 to 1210°C
- ±0.01 or ±0.02°C stability at full range
- ±0.018 to ±0.009°C accuracy
- Large color touchscreen display
- Process calibrator option
- HART communication
- Data logging
- Dual-zone control
- Bluetooth & wireless options
- Vibration, impact & drop tested
- IP20 rated
The Additel ADT875 dry block calibrator offers high performance radial and axial uniformity, speed, stability, and accuracy over a wide temperature range. It features user selectable stability tolerance within specification, user selectable stability time, visual stability indication, and a live clock indicating time to and after stability. Each dry block stores multiple reference probes, which can be used as control probes.
The process calibrator option provides two independent measurement channels, HART communication, data logging on all channels and the ability to document and store up to 1,000 tasks. It also supplies an external reference thermometer input to read PRTs and SPRTs, and 24V loop power which can be enabled and disabled. Additional measurement capabilities include ±30mA, ±30V, and switch measurement, 13 different types of TC measurement, as well as 2, 3, or 4 wire RTD measurement.
The process calibrator option also includes a self calibration function which uses the reference thermometer to run an automated calibration of the internal sensor, essentially removing long term drift and ensuring more accurate calibrations by using only the internal sensor. The original calibration can be restored at any time.
- Additel 9080Cold Junction Kit (incl TC Plug, Cable, S,R,B,K,J,T,E,N)
Order #: 9080ADT
Mfg #: 9080
Availability: Ships in 2-3 weeks$496.00 - Additel 9915-875Carrying Case for ADT875-1210 or ADT878-1210 with Wheels
Order #: 9915-875
Mfg #: 9915-875
Availability:In stock$779.00 - Additel ADT110-875-H-INSERT-BInsert B for ADT875, High Temp
Order #: ADT110-875-H-INSERT-B
Mfg #: ADT110-875-H-INSERT-B
Availability: Ships in 2-3 weeks$480.00 - Additel ADT110-875-H-INSERT-CInsert C for ADT875, High Temp
Order #: ADT110-875-H-INSERT-C
Mfg #: ADT110-875-H-INSERT-C
Availability: Ships in 2-3 weeks$480.00 - Additel ADT110-875-H-INSERT-ZInsert Z for ADT875, High Temp Blank
Order #: ADT110-875-H-INSERT-Z
Mfg #: ADT110-875-H-INSERT-Z
Availability:In stock$314.00 - Additel ADT110-875-L-INSERT-BInsert B for ADT875, Low Temp
Order #: ADT110-875-L-INSERT-B
Mfg #: ADT110-875-L-INSERT-B
Availability: Ships in 2-3 weeks$375.00 - Additel ADT110-875-L-INSERT-CInsert C for ADT875, Low Temp
Order #: ADT110-875-L-INSERT-C
Mfg #: ADT110-875-L-INSERT-C
Availability: Ships in 2-3 weeks$375.00 - Additel ADT110-875-L-INSERT-ZInsert Z for ADT875, Low Temp Blank
Order #: ADT110-875-L-INSERT-Z
Mfg #: ADT110-875-L-INSERT-Z
Availability: Ships in 2-3 weeks$249.00 - Additel ADT110-875-L-SHRT-IKITADT875 Drywell Short Probe Kit
Order #: ADT110-875-L-SHRT-IKIT
Mfg #: ADT110-875-L-SHRT-IKIT
Availability: Ships in 2-3 weeks$2,047.00 - Additel ADT110-875-L-SHRT-MKITADT875 Drywell Short Probe Kit
Order #: ADT110-875-L-SHRT-MKIT
Mfg #: ADT110-875-L-SHRT-MKIT
Availability: Ships in 2-3 weeks$2,047.00 - Additel ADT110-875-TC-INSERT-ARInsert AR for ADT875-1210 Thermocouple Calibration Furn.
Order #: ADT110-875-TC-INSERT-AR
Mfg #: ADT110-875-TC-INSERT-AR
Availability: Ships in 2-3 weeks$1,176.00 - Additel ADT110-875-TC-INSERT-BSInsert BS for ADT875-1210 Thermocouple Calibration Furn.
Order #: ADT110-875-TC-INSERT-BS
Mfg #: ADT110-875-TC-INSERT-BS
Availability: Ships in 2-3 weeks$1,176.00 - Additel ADT110-875-TC-INSERT-ESInsert ES for ADT875-1210 Thermocouple Calibration Furn.
Order #: ADT110-875-TC-INSERT-ES
Mfg #: ADT110-875-TC-INSERT-ES
Availability: Ships in 2-3 weeks$1,176.00 - Additel AM1710-BEND-ADT-17025100Ohm Secondary PRT, -40 to 160C, 1/4", 90deg Bend at 7.5ô
Order #: AM1710-BEND-ADT-17025
Mfg #: AM1710-BEND-ADT-17025
Availability: Ships in 2-3 weeks$1,392.00 - Additel AM1730-12-ADTSecondary PRT, -45 to 420C 1/4"X12", 100 Omega
Order #: AM1730-12-ADT
Mfg #: AM1730-12-ADT
Availability: Ships in 2-3 weeks$1,425.00 - Additel AM1730-12-ADT-17025100Ohm Secondary PRT, -200 to 420degC, 1/4"X12", w/connector
Order #: AM1730-12-ADT-17025
Mfg #: AM1730-12-ADT-17025
Availability: Ships in 2-3 weeks$1,705.00 - Additel AM1730-BEND-ADT-17025100Ohm Secondary PRT, -200 to 420C, 1/4",90deg Bend at 9.75ô
Order #: AM1730-BEND-ADT-17025
Mfg #: AM1730-BEND-ADT-17025
Availability: Ships in 2-3 weeks$1,865.00 - Additel AM1751-12-ADTSecondary PRT, -45 to 660C 1/4"X12", 100 Omega
Order #: AM1751-12-ADT
Mfg #: AM1751-12-ADT
Availability:In stock$2,117.00 - Additel AM1760-12-ADTSecondary Reference SPRT 100 Ohm, 12" x 1/4" -200C-670C
Order #: AM1760-12-ADT
Mfg #: AM1760-12-ADT
Availability: Ships in 2-3 weeks$3,551.00
