Preen Power AFV-31010

Product Highlights

10kVA, 3 Phase In, Single Phase Out. 0~300Vrms, 45~500Hz Output

The AFV is a series of programmable AC power source that can be remote controlled and integrated with other systems for easier operation. Applications include home appliance, electronic, medical equipment, lighting, and etc. With better accuracy and faster response time, the AFV series offers greater advantage for R&D and compliance tests.

Utilized PWM switching technology, AFV provides high quality pure sine waveform with output level up to 2,000kVA. The AC source is coupled with output voltage range of 0~300V and output frequency of standard 45~65Hz or optional 45~500Hz. Users can select communication interfaces of RS-485, RS-232, and optional GPIB. The AFV series also have programming sequence functions of STEP and GRADUAL modes, three phase independent control, and soft start for optional choices.

• Three phase output power from 10-2000kVA.
• CE mark with high electromagnetic compatibility performance.
• Programming Sequence Function: STEP and GRADUAL modes allow users to easily set sequences of start/ end voltage, frequency and run time for testing purposes.
• Optional soft start function to reduce inrush current from motor type UUT.
• Touch screen display for easy operation.
• Optional three phase independent control to set voltage of each phase.
• Comprehensive protection includes over voltage, over current, over load, input under voltage and over temperature with over 20 corresponding error codes and event log for easier trouble shooting.
• Standard RS232 and RS485 interfaces and optional GPIB interface available.
• Patented power module design with compact size for easier maintenance and high power density.
