Keysight N5171B-501 Frequency Range, 9kHz to 1GHz

Achieve faster throughput and greater uptime with the cost-effective performance optimized for manufacturing test
Perform basic parametric testing of components and functional verification of receivers with industry-leading output power
Thoroughly verify receiver performance by simulating complex analog modulation scenarios with multi-function generator capability
Minimize downtime and expenses with self-maintenance solutions and low-cost repairs
Frequency: 9 kHz to 6 GHz
Output Power @1 GHz: -144 dBm to +26 dBm
Phase Noise @1 GHz: (20 kHz offset) -122 dBc/Hz
Frequency Switching: ≤ 800 µs
Harmonics @1 GHz: <-35 dBc
IQ Modulation BW Internal/External: n/av
Non-Harmonics @1 GHz: -72 dBc
Sweep Mode: List, Step
Software-General Purpose: AM, FM, PM, Pulse, Pulse Train Generator
Software-Cellular/Wireless Connectivity: n/a
Software-Audio/Video Broadcasting: n/a
Software-Detection/Positioning/Tracking/Navigation: n/a
Waveform Playback Memory: n/a
Frequency Modulation-Maximum Deviation @1 GHz: 10 MHz
Frequency Modulation-Rate @100 kHz Deviation: DC to 7 MHz
Phase Modulation-Maximum Deviation in Normal Mode: 1.25 rad to 20 rad
Phase Modulation-Maximum Deviation in High-BW Mode: 0.125 to 2 rad
Amplitude Modulation-Maximum Depth: 100%
Amplitude Modulation-Rate : 0 to 50 kHz
Applications Available: Yes
Analog: Yes
