Keysight / Agilent 34924A for Rent, Multiplexer for 34980A, 70-Channel

Order # 34924A-RENT2 | Mfg # 34924A-RENT2

Request a Rental Quote









Have a Question? Speak to a Transcat Rental Expert: 800.264.4059

Have a Question?

Speak to a Transcat Rental Expert at 800.264.4059

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States, Canada, and Puerto Rico only.

Overview

Product Highlights

  • 70 2-wire channels
  • Mixed 2- or 4-wire configurations
  • High-speed reed relays, with relay counter
  • 500 ch/s scanning
  • +/-150V peak, 0.5A switch; 1.5A carry current
  • The Agilent 34924A module for the 34980A Multifunction Switch/Measure Unit is a high-density, high-speed multiplexer for general purpose scanning. It uses reed relays to achieve scan rates up to 500 channels-per-second. Use this module for high-throughput automated test applications as well as high-speed data logging and monitoring tasks.
  • 2- and 4-wire channels may be mixed on the same module. Standard 78-pin Dsub connectors allow for use with standard cables, terminal blocks, or mass interconnect solutions.
