Tektronix DPO5054B for Rent, Digital Phosphor Oscilloscope, 500MHz, 4-Channel, 5 GS/s

Order # DPO5054B-RENT2 | Mfg # DPO5054B-RENT2

Request a Rental Quote









Have a Question? Speak to a Transcat Rental Expert: 800.264.4059

Have a Question?

Speak to a Transcat Rental Expert at 800.264.4059

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States, Canada, and Puerto Rico only.

Overview

Product Highlights

  • 500 MHz, 4-channels
  • 5 GS/s on all four channels
  • Up to 250 megapoint record length with MultiView zoom
  • >250,000 wfms/s max. waveform capture rate with FastAcq acquisition
  • FastFrame segmented memory acquisition mode with up to 290,000 segments and >310,000 waveforms per second capture rate
  • Standard 10 MΩ passive voltage probes with less than 4 pF capacitive loading and 500 MHz analog bandwidth
  • >11 bits vertical resolution using HiRes sampling
  • User-selectable bandwidth limit and DSP filters for lower noise and better measurement accuracy
  • Optional Serial Triggering and Technology Specific Analysis
  • Standard removable hard disk drive (≥480 GB)
  • Microsoft Windows 7 64-bit Operating System
  • USB, LAN (LXI-C)
