Tektronix AFG1062

Product Highlights

The AFG1062 Arbitrary Function Generator provides a waveform generation tool with the best price performance ratio. It includes dual channel, 60 MHz bandwidth and up-to 10 Vp-p output amplitude. The four run modes, 50 built-in frequently-used waveforms and the built-in 200 MHz frequency counter cover most waveform generation needs in your experiment and test jobs. The 3.95-inch TFT LCD, short-cut buttons, USB interface and PC software provide the most intuitive ways to configure the instrument.

• 125 MS/s sampling rate and 14-bit vertical resolution enable great signal fidelity
• 1 mVp-p to 10 Vp-p output amplitude over the whole frequency range
• The intuitive user interface shortens the learning curve for students and other users
• 2 to 8,192-point length of memory for user-defined arbitrary waveforms
• 64-MByte internal non-volatile memory for arbitrary waveform storage
• Standard USB host/device for memory expansion and remote control
• Menu and online help are in English and Simplified Chinese
• Compact form factor for stacking on other bench instruments to save valuable bench space
• Free ArbExpress makes user defined waveforms editing extremely easy
• Compatible with TekSmartLab for easy teaching and learning
