Siglent SPD1305X

Order # SPD1305X | Mfg # SPD1305X
$328.00
arrow_drop_down

Tariff fees or manufacture imposed surcharges may be applicable.

Overview

Product Highlights

  • Single path high-precision programmable voltage output:
    • SPD1168X: 16 V/8 A, total power up to 128 W
    • SPD1305X: 30 V/5 A, total power up to 150 W
    • Stable, reliable, Low ripple and noise_≤ 350 uVrms/3 mVpp; < 2 mArms
  • Fast transient response time: < 50 µs
  • 5 digit Voltage, 4 digit Current Display, Minimum Resolution: 1 mV/1 mA
  • Supports front panel timing output functions
  • 2.8 inch true color TFT- LCD 240 x320 display
  • 2 types of output modes: Two-wire output mode, 4-wire compensation output mode, Maximum compensation voltage 1V.
  • 100/120/220/230 V compatible design to meet the needs of different power grids
  • Intelligent temperature-controlled fanreduces noise
  • Clear graphical interface, with the waveform display function
  • Internal 5 groups of system parameter save/recall

    • Each Unit Includes

    • PC software: Easypower, supports SCPI, LabView driver

    Technical Resources

    <
    Siglent SPD1000X Datasheet
