Chroma 61505 for Rent, AC Source, 0 to 300V, 15 to 1kHz, 4kVA, 1 Phase

Product Highlights

The Chroma 61505 AC power source sets up the new standard for high performance AC power source. It equips with all powerful features such as power line disturbance (PLD) simulation, programmable output impedance, comprehensive measurement functions, wave-shape synthesis and regulation test software. The AC+DC modes extend the applications not only pure AC voltage but also DC component for testing DC offset in laboratory. The Chroma 61505 AC power sources give users the maximum choices from R/D design verification, quality assurance, to production test.

With the versatile programmable voltage functions and easy-use operation software, the 61505 AC source enables users to perform the pre-compliance tests against IEC 61000-4-11 and compliance test against IEC 61000-4-13/-4-14/-4-28 immunity test regulations. With low impedance and low voltage harmonic character, model 61505 can be a standard source for 230V/16A IEC 61000-3-2 testing. Chroma's 61505 AC power source has built in a 16-bit measurement circuit and firmware utilities to measure the steady and transient responses of true RMS voltage, current, true power, VA (apparent power), VAR (reactive power), power factor, current crest factor, peak repetitive current and inrush current.

Specifications of the Chroma 61505 AC Power Source includes:
