Overview
Product Highlights
This unique fitting makes a metal to metal seat on the transmitter and a Quick-test hose can be attached on the other side
Connects through the bleeder screw port on a DP transmitter
Made in USA
Weight: 1.17 oz / 33 grams
Length: 2.16 in / 55 mm
Width: 0.56 in / 15 mm
Height: 0.56 in / 15 mm
Compatible with: Rosemount 2051 Series DP Pressure Transmitters, Rosemount 3051 Series DP Pressure Transmitters, Yokogawa EJ series DP Pressure Transmitters, Anderson Greenwood M25 Block and Bleed Valves, Anderson Greenwood M251 Block and Bleed Valves
Materials: Stainless Steel
Max Operating Temperature: 140 °F / 60 °C
Max Pressure: 5000 PSI / 350 bar / 35 MPa
Max Vacuum: 0 InHg / 0.0 kPa
Media Compatibility: Air, Inert Gas, Natural Gas, Petroleum Based Oil, Water
Min Operating Temperature: 0 °F / -18 °C
Seal Materials: Buna-N
Wrench Size: 9/16 In / 15 mm
Wrench Size: 15 mm / 9/16 in
End 1 Connector: 5/16-24 Male DP Transmitter/Gauge valve
