Ralston Instruments QTHA-2FBA 1/4" NPTF x Female Quick-Test No Check-valve, Brass Adapter

1/4"NPTF x Female Quick-Test No Check-valve,Brass

Order #: QTHA-2FBA

Mfg #: QTHA-2FBA

Questions about availability or need help? Contact Us:

$21.66

Qty

Ralston Instruments QTHA-2FBA 1/4" NPTF x Female Quick-Test No Check-valve, Brass Adapter

1/4"NPTF x Female Quick-Test No Check-valve,Brass

Order #: QTHA-2FBA

Mfg #: QTHA-2FBA

$21.66

Availability:

In stock

Tariff fees or manufacture imposed surcharges may be applicable.

Connect to a pressure gauge or other device with Male NPT connections to a Ralston hand pump or nitrogen calibration device
Install with thread tape once onto any male NPT pressure gauge then use the Quick-test connection to quickly connect or disconnect from any Ralston hand pump, nitrogen calibration device or other Quick-test adapter
Saves the threads on a pressure gauge by not needing to make and remake the connection with thread sealant
Made in USA
Weight: 2.05 oz / 58 grams
Length: 1.52 in / 39 mm
Width: 0.75 in / 20 mm
Height: 0.75 in / 20 mm
Materials: Brass
Max Operating Temperature: 225 °F / 105 °C
Max Pressure: 5000 PSI / 350 bar / 35 MPa
Max Vacuum: 0 InHg / 0.0 kPa
Wrench Size: 3/4 In / 20 mm
Wrench Size: 19 mm / 23/32 in
End 1 Connector: 1/4" Female NPT (ASME B1.20.1)
End 1 Direction: Left
End 2 Connector: Female Quick-test
End 2 Direction: Left

Ralston Instruments QTHA-2FBA Datasheet
