Enerpac RC-50 Gen.Purpose Hydraulic Cylinder, 4.9 Ton Capacity, .63" Stroke
Order #
RC50
|
Mfg #
300549
Tariff fees or manufacture imposed surcharges may be applicable.
Overview
Product Highlights
- Unique GR2 Bearing Design, reduces wear, extending life
- Base mounting holes enable easy fixturing
- Designed for use in all positions
- High strength alloy steel for durability
- Redesigned cylinder thread protector for ease of use
- Heavy-duty, pretensioned spring improves retraction speed
- Baked enamel finish for increased corrosion resistance
- CR-400 coupler and dust cap included on all models
- Plunger wiper reduces contamination, extending
Specifications
| Cylinder capacity |
5 tons (4.9 maximum) |
| Stroke length |
0.63 inches |
| Effective area |
0.99 square inches |
| Oil capacity |
0.62 cubic inches |
| Cylinder bore diameter |
1.13 inches |
| Collapsed height |
1.63 inches |
| Extended height |
2.25 inches |
| Outside diameter |
2.31 inches |
| Weight |
2.2 lb. |
