Dwyer Instruments BTT-N00-3 Wall Mount Temperature Transmitter 4 to 20 mA Output

The Series BTT-E/N Temperature Transmitters offer transmitter output signals with the same form and fit as our popular Series TE-E/N thermistor and RTD sensors for Building Automation and HVAC installations.

North American wall mount temperature transmitter with 4 to 20 mA output

• Transmitter signal offers reliable accuracy for installations with long wire runs between the transmitter and the receiver/controller

• Accuracy: ± 0.5 °C
• Compliance: CE
• Current Output: 4 to 20 mA
• Electrical Connection: Screw Terminal
• Enclosure Ratings: IP20
• Measurement Type: RTD
• Mounting Orientation: North American Style Wall Mount
• Output Signal: Current
• Process Temperature, Max: 122 °F
• Process Temperature, Min: 32 °F
• Response Time: 100 ms
• Sensor Type: Pt1000
• Supply Power Type: DC
• Supply Voltage: 13 to 36 Vdc
• Thermal Effects: ± 0.01%/°C
• Weight: 73.7 g

Application

• Room or indoor building space temperature monitoring

Each Unit Includes

• 1 - Wall mount temperature transmitter (BTT-N00-3)
