Dwyer Instruments 628-11-GH-P1-E1-S1 Single Pressure Transmitter 0 - 150.0 PSI

The Series 628 Industrial Pressure Transmitters are ideal for OEMs with 1% full-scale accuracy sensors. The corrosion resistant 316L stainless steel wetted parts allow the transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. Series 628 are available in absolute and gage pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.

Single Pressure Transmitter 0 - 150.0 PSI

• NEMA 4X rated enclosure provides protection in harsh environments permitting outdoor monitoring or in areas where dust and particulate matter exists
• Robust 316L SS oil filled sensor provides shock and vibration resistance ensuring stability in controlling pressure for process applications
• A wide range of models and connections that can meet pressure measurement specifications from low to very

• Accuracy: ± 1 %
• Accuracy Detail: 626: 0.25% FS; 626: 0.20% RSS; 628: 1.0% FS; 628: 0.5% RSS; 626 Absolute Ranges: 0.5% FS; 626 absolute ranges: 0.30% RSS. (Includes linearity, hysteresis, and repeatability.)
• Burst Pressure: 750 psi Maximum
• Compensated Temperature, Max: 175 °F
• Compensated Temperature, Min: 0 °F
• Compliance: CE
• Compliance Note: CE, Optional: NSF/ANSI 61/372, ANSI/UL 218, ANSI/UL 508, NEPA 20
• Electrical Connection: Cable Gland with Cable
• Electrical Output: 4 to 20 mA
• Enclosure Ratings: IP66, NEMA Type 4X
• Housing Construction: General Purpose Housing
• Loop Resistance: 0 to 1000 Ω max
• Materials, Wetted: 316L Stainless Steel
• Measurement Pressure Type: Gauge
• Measurement Pressure, Max: 150 psi
• Measurement Pressure, Min; 0 psi
• Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
• Mounting Orientation: Not Position Sensitive
Operating Temperature, Max: 200 °F Operating Temperature, Min: 0 °F
• Output Detail: 4 to 20 mA
• Output Signal: Current
• Power Consumption: 38 mA
• Process Connection Size: 1/4 in
• Process Connection Type: NPT Male
Proof Pressure: Up to 300 psi
• Response Time: 300 ms
• Supply Power Note: 10 to 30 VDC (for 4 to 20 mA, 0 to 5, 1 to 5, 1 to 6 VDC outputs); 13 to 30 VDC (for 0 to 10, 2 to 10 VDC outputs); 5 VDC ± 0.5 VDC (for 0.5 to 4.5 VDC ratio to metric output), 10 to 35 VDC (for 4 to 20 mA with to CB option); 13 to 35 VDC or isolated 16 to 33 VAC (for selectable output with to CB option)
• Supply Power Type: DC
• Supply Voltage: 10 to 30 Vdc
• Thermal Effects: ± 0.02% FS/°F (includes zero and span)
• Weight: 283 g

Applications

• Compressors
• Pumping systems
• Irrigation equipment
• Hydraulic
• Industrial process monitoring

Each Unit Includes

• 1 - Single Pressure Transmitter (628-11-GH-P1-E1-S1)
