Dwyer Instruments 668-16

Order # 668-16

Mfg # 668-16

800-828-1470

$280.30

Dwyer Instruments 668-16

Order # 668-16 | Mfg # 668-16

$280.30

Ships in 3-4 weeks

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States and Canada only.

Overview

Service: Air and non-conductive gases.
Accuracy: ±1% of full scale (RSS), (includes non-linearity, hysteresis, and non-repeatability).
Temperature Limits: Operating: 0 to 150°F (-18 to 65°C), Storage: -40 to 185°F (-40 to 85°C).
Pressure Limits: 10 psig (0.69 bar).
Compensated Temperature Range: 0 to 150°F (-18 to 65°C).
Thermal Effects: 0.033% FS/°F (0.18% FS/°C).
Supply Voltage: 12-30 VDC.
Output: 4 to 20 mA, 2-wire.
Zero and Span Adjustment: ±1 mA, non-interactive.
Response Time:
Loop Resistance: 0-800 ohms.
Electrical Connection: Terminal strip.
Pressure Connection: 3/16" O.D. fitting for 1/4" I.D. tubing.
Housing: Fire retardant glass filled polyester.
Weight: 3 oz (85 g).
Agency Approval: CE.

Dwyer Instruments Series 668 Compact Differential Pressure Transmitter Datasheet
