Newport Electronics FMA-A2309

Massflow 0-10 SLM

Order #: FMA-A2309

Mfg #: FMA-A2309

Questions about availability or need help? Contact Us:

(800) 633-0561
Call for price
Call for price

Newport Electronics FMA-A2309

Massflow 0-10 SLM

Order #: FMA-A2309

Mfg #: FMA-A2309

Call for price
Call for price
Availability: Ships in 2-3 weeks
Available Promotions

Only need this item for a short time? Learn about rentals

Questions about this product? Speak to an expert

Product Highlights

  • Massflow 0-10 SLM
  • ±1% Accuracy
  • Linear Output
  • Low Cost
  • Thermal Technology
  • For Flow Rates up to 75 SLM
  • Power Supply Included
  • Comes standard with 5-point NIST cert
  • Accuracy: ±1% of full scale including linearity
  • Repeatability: ±0.15% full scale or better
  • Turndown Ratio: 100:1
  • Response Time: 5 seconds
  • Gas Ambient Temperature: 0 to 50°C (32 to 122°F)
  • Temperature Coefficient: 0.05% full scale per 1°C or better
  • Pressure Coefficient: 0.01% full scale per psi or better
  • Minimum Pressure Requirements:
  • Meters: 1 inch of H2O
  • Controllers ≤1 SLM: 1 psi
  • Controllers >20 SLM: 20 psi
  • Differential Pressure for Mass Flow Controllers:5 LPM: 20 to 40 psi standard
  • Maximum Gas Pressure: Polyacetal: 250 psig 316 SS: 500 psig
  • Leak Integrity: 1 x10-6 cc/min of He or better
  • Wetted Parts: Standard: Polyacetal, FKM O-rings Optional: 316 SS, FKM O-rings
  • Connections: 1/4 FNPT standard; 1/4" compression fitting for all stainless steel models
  • Input/Output Connection: 9-pin sub-D connector
  • Control Signal: 0 to 5 Vdc
  • Control Valve: Electromagnetic normally closed
  • Output signal: Linear 0 to 5 Vdc, 1000 Ω min load, 4 to 20 mA, 500 Ω loop resistance
  • Input Power: Meters: 24 Vdc @ 150 mA, 115 Vac, 220 Vac with AC adaptor Controller: 24 Vdc @ 300 mA, 115 Vac, 220 Vac with AC adaptor
  • Weight: 1.25 kg (2.75 lb) with power supply
