Omega Engineering RDXL12SD

Portable Thermometer/Datalogger 12-Channel w/2 GB SD Card

Order #: RDXL12SD

Mfg #: RDXL12SD

Questions about availability or need help? Contact Us:

(800) 633-0561
Call for price
Call for price

Omega Engineering RDXL12SD

Portable Thermometer/Datalogger 12-Channel w/2 GB SD Card

Order #: RDXL12SD

Mfg #: RDXL12SD

Call for price
Call for price
The portable RDXL12SD model is a handheld thermometer/data logger with backlight display and built-in analysis functions. The data loggers are powered by an internal battery and are capable of sampling, processing and displaying measurements without being connected to a computer.
Availability: Ships in 3-4 weeks
Available Promotions

Only need this item for a short time? Learn about rentals

Questions about this product? Speak to an expert

Product Highlights

  • 4-channel digital T/C or RTD input thermometer with 2 GB SD card
  • SD Card, Real-Time Data Logger
  • Input Signals: T/C K, J, T, E, R/S, and RTD Pt100 Ω Measurement
  • Display All Input Channels Simultaneously
  • Data Hold, Record Max and Min Reading
  • RS232/USB PC Computer Interface
  • LCD with Green Light Backlight, Easy Reading
  • SD Card Capacity: 1 to 16 GB
  • Embedded Microcontroller: Custom one-chip LSI device
  • LCD Display: 82 x 61 mm (3.23 x 2.40") with green color backlight
  • 12 Channels: T1, T2, T3, T4, T5, T6, T7, T8, T9, T10, T11 and T12
  • Sensor: Type J, K, T, E, R/S thermocouple probe Pt100 Ω RTD (European curve) for RDXL4SD model only
  • Resolution: 0.1/1°C or °F
  • Sampling Time: 1 to 3600 seconds
  • Memory Card: SD memory card 1 to 16 GB
  • Memory Recall: Max and min value
  • Sampling Time of Display: Approx 1 second
  • Data Output: RS232/USB PC computer interface
  • Power Off: Auto shut off saves battery life or manual off by push button
  • Operating Temperature: 0 to 50°C (32 to 122°F)
  • Operating Humidity: Less than 85% RH
  • Power Supply: Alkaline or heavy-duty DC 1.5V battery (UM3, AA) x 6 "AA"
  • Power Current: Approx DC 30 mA
  • Weight: 489 g (1.08 lb)
  • Dimensions: 177 H x 68 W x 45 mm D (7 x 2.7 x 1.9")
