Mensor CPT6020-10INH2OG

Pressure Transducer 0-10 in H2O Gauge at 20DegC

Order #: CPT6020-10INH2OG

Mfg #: CPT6020-10INH2OG

Questions about availability or need help? Contact Us:

(800) 633-0561
Special Price $1,210.00 Regular Price $1,287.00

Mensor CPT6020-10INH2OG

Pressure Transducer 0-10 in H2O Gauge at 20DegC

Order #: CPT6020-10INH2OG

Mfg #: CPT6020-10INH2OG

Special Price $1,210.00 Regular Price $1,287.00
Availability: Item ships in about Call for availability
Available Promotions

Only need this item for a short time? Learn about rentals

Questions about this product? Speak to an expert

Product Highlights

The CPT6020 Process Pressure Transducer is a self-contained pressure sensing device that provides high accuracy pressure measurements. This transducer incorporates a low hysteresis silicon sensor with electronically compensated pressure linearity over the compensated temperature range. The CPT6020 transducer is characterized over the full pressure and temperature range to achieve 0.020% FS accuracy. This specification includes linearity, hysteresis, repeatability and temperature errors. Also featured is an output which is updated at a rate of 50 readings per second (20 ms).

  • Accuracy: 0.020% FS
  • Range: 0-10 in. H2O (25 mbar) up to 15,015 psi (1001 bar)
  • Temperature compensation: 0 to 50C
  • RS-232 or RS-485 communication
  • Compact rugged design

Each Unit Includes

  • Pressure Transducer
  • Instructions
  • ISO 17025 A2LA Accredited Calibration Certificate
  • Pressure Adapter
  • 5 ft Connection Cable with Flying Leads
