Fluke Networks FQM-SFP-M Fiber Quickmap with Power Meter Set; Multimode Fault Finder
FIBER QUICKMAP WITH POWER METER SET; MULTIMODE FAULT FINDER

Order #: FQM-SFP-M

Mfg #: 4774960

Questions about availability or need help? Contact Us:

(800) 633-0561
$5,634.99

Fluke Networks FQM-SFP-M Fiber Quickmap with Power Meter Set; Multimode Fault Finder

FIBER QUICKMAP WITH POWER METER SET; MULTIMODE FAULT FINDER

Order #: FQM-SFP-M

Mfg #: 4774960

$5,634.99
Availability: Ships in 3-4 weeks
This product is available for shipping to the United States only.
This product is available for shipping to the United States only.
This product is available for shipping to the United States only.

Product Highlights

  • Works on multimode fiber, 50/125µm and 62.5/125 µm
  • 850 nm output wavelength. Measure up to 4,921 feet (1,500 metres) of fiber in seconds
  • Locate severe bends, high-loss splices, breaks and dirty connectors in multimode fiber
  • Measure and locate high-loss splices
  • Locate the end of a fiber
  • Find potential sources of high bit error rates caused by reflectance from dirty or poor connections
  • Detects live optical signals before it begins testing
  • Quick set-up. Connect your fiber and press the Test button. No lengthy set-up necessary
  • Find problems quickly. Six-second test time—no more blind troubleshooting that can waste hours
  • Change the Index of Refraction (IOR) to improve fiber length accuracy
  • Visible in dark areas. Backlighted display turns off automatically
  • Removable SC adapter is easily cleaned
  • Optional LC, ST and FT interchangeable adapters are available
  • Long battery life, 1,500 tests (typical) from 2 AA alkaline batteries
  • Rugged construction; vibration and drop tested to 1 meter

Each Unit Includes

  • multimode fiber fault locator unit
  • screw on interchangeable SC adapter
  • UPC-UPC 2-meter patch cord
  • carrying case
  • 4-language Quick Reference Guide (manuals in 9 languages available on-line)
  • safety instruction manual
  • batteries
  • SimpliFiber Pro optical power meter and SC adapter are also included
