The Siglent SNA5000-AFR is an optional software feature for the SNA5000A series Vector Network Analyzers, specifically designed for Automatic Fixture Removal. It allows users to de-embed test fixtures, adapters, and cables from measurements, providing accurate S-parameter results of the device under test (DUT) by removing fixture influences.
- Available in ranges up to 8.5 GHz and 26.5 GHz
- 125 dB dynamic range and a 0.003 dBrms trace noise
- Supports 2/4-port S-parameters, differential-parameters, and time-domain reflectometry (TDR) for impedance analysis
- Includes specialized tools for measuring Q-factor, bandwidth, insertion loss, and gain compression
- Features internal Bias-Tees (active devices) and support for external USB power meters
- User Interface: 12.1-inch touch display with a 1280 x 800 resolution
- Supports advanced calibration methods including SOLT, SOLR, TRL, and fixture simulation
Applications
- De-embedding Test Fixtures
- High-Speed PCB Design
- Component Characterization
- Production and R&D
- TDR/TDT Analysis
Each Unit Includes
- Auto Filter Test function for SNA5000A series
