Keysight E36154A DC power supply, single-output, auto-range: 30V, 80A, 800W

Order # E36154A | Mfg # E36154A
$3,900.00
arrow_drop_down

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States and Canada only.

Overview

Product Highlights

Features

  • Plenty of usable power
    • Autoranging
    • Peak power handling up to 3X max power rating
  • Safe, clean, and reliable power
    • Low output ripple and noise
    • Excellent line/load regulation
    • 2-wire or 4-wire remote sense
    • Detachable high current front binding post
    • Over-voltage, over-current, and over-temperature protection
  • Convenient benchtop capabilities and intuitive interfaces
    • Thermal-control fan speed for minimal acoustic noise
    • 4-wire front output terminal including sense and ground
    • 4.3-inch LCD color display
    • Individual knobs for voltage and current
    • LAN/LXI, USB and GPIB (upgrade option) interfaces
  • Advanced characterization
    • Built-in voltage and current measurements
    • Data logging
    • Output sequencing and syncing with digital I/O
    • LIST mode programming
    • Low range current measurement
    • Adjustable voltage slew rate
    • Scope View (upgrade option)
    • Arbitrary waveform generator (AWG) (upgrade option)
  • Application Software and Automation
    • BV0003B Pathwave BenchVue Power Supply App
    • BV9200B/BV9201B BenchVue Advanced Power Control and Analysis

Technical Resources

Specifications

Model E36154A E36155A
Power Output 800W 800W
No. of Channel 1 1
DC Output Rating (0 to 40 °C) 0 to 30 V 0 to 60 V
0 to 80 A 0 to 40 A
Load Regulation ± (% of output + offset)
Voltage < 0.01% + 2 mV
Current < 0.1% + 2 mA
Line Regulation ± (% of output + offset)
Voltage < 0.01% + 2 mV
Current < 0.1% + 2 mA
Output Ripple and Noise (at approximately 23 °C)
Normal mode voltage, Vpp (20 Hz to 20 MHz) < 75 mV
Normal mode voltage, Vrms (20 Hz to 10 MHz) < 5 mV
Programming Accuracy ± (% of output + offset) at 23 °C ± 5 °C for 12 months
Voltage 0.03% + 6 mV 0.03% + 10 mV
Current 0.1% + 20 mA 0.1% + 10 mA
Readback Accuracy ± (% of output + offset) at 23 °C ± 5 °C for 12 months
Voltage 0.04% + 6 mV 0.04% + 10 mV
Current 0.1% + 20 mA 0.1% + 10 mA
Low Range Current 0.1% + 5 mA 0.1% + 4 mA
Load Transient Recovery Time
Voltage Settling Band 75 mV 150 mV
Time < 1 ms
