GW Instek GPT-9612 Value Hi-Pot Tester, AC/IR 100VA

Order # GPT-9612 | Mfg # GPT-9612
$1,146.20
  • 100VA AC Test Capacity
  • Tests: AC/IR
  • AC Withstanding: 5kV AC, 20mA
  • Insulation Resistance: 50/100/250/500/1000V DC, 2000 Mohms
  • RMS Current Measurement
arrow_drop_down

Tariff fees or manufacture imposed surcharges may be applicable.

Overview

The Instek GPT-9612 Electrical Safety Hi-Pot Tester supports tests of the safety standards such as IEC, EN, UL, CSA, GB, JIS and more. The GPT9612 unit is equipped with a PWM amplifier which impedes influence from the input AC voltage fluctuation and ensures a stable voltage output.

  • Insulation Resistance: 50/100/250/500/1000 Vdc, 2000 Mohms
  • AC Withstanding: 5 kVac, 20 mA
  • 100VA AC Test Capacity
  • 240x48 Ice Blue Dot Matrix LCD
  • Auto W-I and I-W Mode
  • True RMS Current Measurement
  • Zero Crossing Turn-on Operation
  • Safety INTERLOCK Function
  • PWM Switching Amplifier to Enhance the Power Efficiency and Reliable Testing
  • Automatically Switching Input Source for Universal Input Voltage

Each Unit Includes

  • 1 - Electrical Safety Analyzer with Withstanding Voltage and Insulation Resistance, AC (GPT-9612)
  • 1 - Quick Start Guide
  • 1 - CD with Complete User Manual
  • 1 - Power Cord
  • 1 - Interlock Key
  • 1 - Remote Terminal Male Plug
  • 1 - Test Lead (GHT-114)

Technical Resources
