GW Instek GPT-9503 150VA Multi-channels Hipot Tester (H or X)

The Instek GPT-9503 Multi-Channel Hi-Pot Tester has a built-in 8-channel scanner and meets safety regulations IEC, EN, UL, CSA, GB, JIS and more. The GPT9503 unit meets the needs of the main test items of general electronic components or winding components during routine tests.

• 150VA AC Test Capacity
• 3 in 1 Tester: AC, DC, IR
• Built-in 8-Channel Scanner
• Status of 8-Channels can be set to H or X according to the test requirements
• 480 x 272 Color TFT LCD
• Test parameter Export/Import through USB host
• Statistics (counter) function
• Insulation resistance measurement up to 10GOhm
• Open/Short Check (OSC)
• ARC detection
• Multi-language: Traditional/Simplified Chinese, English
• Interface: RS-232C and USB host/device

Each Unit Includes

• 1 - Multi-Channel Hipot Tester with High Voltage Scan (GPT-9503)
• 1 - Quick Start Guide
• 1 - CD (Complete User Manual)
• 1 - Power Cord
• 1 - Test Leads (GHT-115)
• 1 - Black Test Lead (GHT-116B)
• 8 - Red Test Leads (GHT-116R)
