Additel ADT158EX-02-GP6K-PSI-M Digital Pressure Module, 0 to 6000 psi, Gauge, M20X1.5M

Order # ADT158EX-02-GP6K-PSI-M | Mfg # ADT158EX-02-GP6K-PSI-M
$1,857.00
arrow_drop_down

Tariff fees or manufacture imposed surcharges may be applicable.

This product is available for shipping to the United States, Canada, and Puerto Rico only.

Overview

Product Highlights

  • Pressure ranges to 60,000 psi (4,200 bar)
  • Pressure measurement accuracy of 0.02% FS
  • Intrinsically Safe (Ex)
  • Fully temperature compensated accuracy

With advanced microprocessor technology and state-of-the-art silicon pressure sensors, Additel's 158Ex series Digital Pressure Modules provide an accurate, reliable, and economic solution for wide range of pressure applications. Our intrinsically safe (Ex) models are up to the task of providing the best possible results, even in hazardous environments. In order to reach the best performance, every silicon pressure sensor in the module has been specially aged, tested and screened before assembly. Designed as field switchable pressure modules for use with Additel 273Ex and 260Ex handheld devices, the Additel 158Ex is unmatched in performance and reliability. If intrinsic safety is a critical requirement for your workload, we have you covered when you combine our model ADT273Ex or ADT260Ex handheld calibrators with any of our ADT158Ex pressure modules.

Features

  • Gauge pressure measurement accuracy of 0.02% FS
  • Pressure ranges to 60,000 psi (4,200 bar)
  • Intrinsically Safe with ADT260EX and ADT273EX
  • Advanced temperature compensation
  • ISO 17025 accredited calibration and data included

Technical Resources

Specifications

Standard Accuracy
  CPXXX GPXXX
Operating temperature -10°C to 50°C (14°F to 122°F)
Storage temperature -20°C to 70°C (-4°F to 158°F)
Relative humidity 95% RH
Pressure connections (for external use only) 1/4NPT, 1/2NPT, 1/4BSP, 1/2BPS, M20x15
Enclosure (for external use only) SS enclosure
Intrinisic Safety ATEX certified intrinsically safe only with ADT260EX & ADT273EX
Dimensions (Dia x H) 33 mm x 123 mm (1.3" x 4.84")
Weight 0.4 kg (0.99 lb)
Warranty 1 Year
