Fluke Calibration 6532-70M Deadweight Tester

One-year measurement uncertainty is ± 0.02% of reading from 10% to 100% with one Q-RPT, and from 1% to 100% with two Q-RPTs
Low torque variable volume allows for pressure generation up to 200 MPa (30,000 psi) with minimal physical effort
Separate fine adjustment tool for maximum, superfine control resolution
User defined resolution and ready limits enable user to optimize performance based on DUT specifications
High pressure isolation valve and pressure relief valve protect the low pressure reference transducer from over pressure when high pressure reference transducer is active
AutoRange feature optimizes measurement and safety features for the specific range of the instrument being calibrated
Simple rezeroing while vented at atmospheric pressure
Simple, objective pressure "ready/not ready indicator with user adjustable criteria to ensure repeatable results among operators
Not dependent on local gravity or ambient temperature
Sets and reads any pressure value directly in any unit of measure, without moving weights
Built-in priming system to fill system with test fluid and purge unwanted air to assure smooth operation
Optional foot switch accessory allows hands-free data collection when running AutoTests

Fluke Calibration 6532-70M Electronic Deadweight Tester, 70Mpa (10K PSI) Extended Range
