The UNI-T MSO8000HDJITTER Advanced Jitter Analysis and Eye Diagram option transforms MSO8000HD oscilloscopes into a comprehensive signal integrity analysis platform, delivering professional-grade jitter measurements and eye diagram testing capabilities essential for modern high-speed digital communications. This advanced option provides the critical timing characterization tools needed to ensure signal integrity, validate clock synchronization, and analyze transmission quality in complex electronic systems.
Engineered for professionals working with high-speed digital interfaces, serial data communication systems, and precision timing applications, the MSO8000HD-JITTER option delivers industry-standard measurements with the accuracy and depth required for both design validation and production testing. The comprehensive analysis views and measurement capabilities enable engineers to quickly identify timing issues, quantify jitter sources, and optimize system performance.
- Eye Diagram, Trend Chart, Histogram, TIE spectrum, and Bathtub Curve
- TIE, Cycle-to-Cycle Jitter, Period Jitter, and advanced decomposition
- Professional jitter decomposition: Total Jitter (TJ), Random Jitter (RJ), Deterministic Jitter (DJ)
- Data-Dependent Jitter (DDJ), Duty Cycle Distortion (DCD), and Inter-Symbol Interference (ISI)
- Statistical jitter extrapolation: TJ@BER calculations for reliability predictions
- Multi-domain correlation: Time domain waveforms with frequency domain jitter spectra
- Real-time eye diagram analysis with automated parameter measurements
- Customizable measurement templates for repeatable test procedures
- High-resolution timing measurements with sub-picosecond precision
- Compatible with NRZ, PAM-4, and other high-speed signaling formats
- Automated test report generation with statistical analysis
- Integration with protocol analysis options for complete system validation
- Compatible Models: MSO8804HD
- Software license activation - no hardware modification required
- Full oscilloscope bandwidth for maximum timing resolution
- Optimized for 10-20 GSa/s operation depending on channel configuration
- Immediate functionality after activation
- Full integration with existing oscilloscope measurement capabilities
Applications
- High-Speed Serial Data Analysis
- Clock and Timing Validation
- System Integrity Debugging
- PAM-N Analysis
Each Unit Includes
- 1 - Advanced Jitter Analysis and Eye Diagram Option (MSO8000HD-JITTER)
