The UNI-T MSO8000HD8B10B 8b/10b Signal Analysis option provides comprehensive analysis and decoding capabilities for 8b/10b encoded serial data streams commonly used in high-speed communication systems. This encoding scheme, fundamental to technologies like Gigabit Ethernet, Fibre Channel, SATA, and many other high-speed serial interfaces, requires specialized analysis tools to decode data content, verify timing compliance, and identify transmission errors.
Essential for validating 8b/10b-based communication links, the MSO8000HD-8B10B option automatically decodes the encoded bit stream back to original 8-bit data while providing detailed analysis of code violations, running disparity errors, and timing characteristics. The real-time analysis capability enables immediate identification of link quality issues and protocol compliance problems.
- Automatic Data Decoding - Converts 8b/10b encoded streams back to original 8-bit data values for analysis
- Real-Time Analysis - Immediate decoding and error detection without offline processing
- Code Violation Detection - Identifies invalid 8b/10b code sequences and transmission errors
- Running Disparity Tracking - Monitors DC balance and detects disparity violations
- Special Character Recognition - Decodes K-codes and control characters used for frame alignment
- Timing Analysis Integration - Correlates decoded data with physical layer timing measurements
- Compatible Models: MSO8804HD, MSO8504HD
- Software license activation - no hardware modification required
- Immediate functionality after activation
- Integrates with existing trigger and measurement systems
- Compatible with all MSO8000HD probing solutions
Applications
- High-Speed Data Communications
- Embedded System Debugging
- Protocol Compliance Testing
- Signal Integrity Analysis
Each Unit Includes
- 1 - 8b/10b Signal Analysis Option for MSO8000HD Oscilloscopes (MSO8000HD-8B10B)
