The UNI-T UPO7000LPWR software unlock transforms the UPO7000L Series Oscilloscopes into a fully equipped power analysis workstation. Designed for power electronics engineers, system integrators, and embedded developers, this option adds a complete suite of automated measurements to evaluate switching behavior, power quality, efficiency, and dynamic performance.
From ripple and switching loss to Bode plots and harmonic distortion, this feature set helps users uncover real-world inefficiencies and instability in their designs - without the need for external analyzers or manual math setups.
- Advanced Power Analysis Option
- For UPO7000L Oscilloscopes
- Automated switching loss integration with adjustable turn-on/off detection
- SOA diagrams with real-time device stress boundaries
- Ripple and noise overlays with high-resolution vertical scaling
- True efficiency calculation with math-based input/output power capture
- Bode plot mode with frequency sweep up to 20 MHz
- Harmonic spectrum analysis on voltage or current waveforms
- Pass/fail margin testing and PDF report generation
Applications
- DC-DC converter development and benchmarking
- Motor drive and inverter system validation
- High-efficiency LED driver analysis
- Battery-powered embedded design optimization
- EMI root cause analysis and pre-compliance checks
- University and training labs teaching real-world power electronics
Each Unit Includes
- 1 - Advanced Power Analysis Option (UPO7000L-PWR)
