The UNI-T UPO7000LCANFD software unlock enables real-time decoding, triggering, and analysis of CAN FD (Controller Area Network with Flexible Data Rate) on the UPO7000L Series oscilloscopes. This feature is essential for automotive engineers working with next-generation ECUs, advanced driver assistance systems (ADAS), EV battery management, and high-speed body electronics.
Unlike classical CAN, CAN FD supports larger payloads and faster data rates—making reliable signal decoding and timing validation even more critical.
- CAN-FD Automotive Serial Bus Triggering and Analysis Option
- For UPO7000L Oscilloscopes
- Trigger on frame ID, data content, CRC errors, or bit timing issues
- Real-time waveform + protocol decode overlay
- Support for both ISO and non-ISO CAN FD formats
- Compatible with high-voltage and isolated differential probes
- Time-correlated with analog behavior for full-system visibility
- Exportable event tables with time stamps, message ID, and decoded values
Applications
- Electric vehicle (EV) and hybrid system development
- ECU timing validation and signal traceability
- Safety-critical message monitoring in braking or steering systems
- Automotive gateway and domain controller debugging
- OEM and Tier 1 validation labs
- Teaching CAN FD fundamentals and timing behavior
Each Unit Includes
- 1 - CAN-FD Automotive Serial Bus Triggering and Analysis Option (UPO7000L-CANFD)
