The UNI-T UPO7000LAUDIO software unlock enables decoding and triggering for the most widely used digital audio serial protocols, including I2S (Inter-IC Sound), Left Justified (LJ), Right Justified (RJ), and TDM (Time Division Multiplexed audio). Ideal for engineers working in automotive infotainment, professional audio, digital signal processing, or embedded audio systems, this feature gives users deep visibility into timing, synchronization, and data payloads across multi-bit audio streams.
Whether debugging codec interfaces or validating synchronization between digital microphones and DSPs, this option makes audio-level protocol validation seamless and reliable.
- Audio Serial Bus Trigger and Analysis Option
- For UPO7000L Oscilloscopes
- Trigger on frame start, word select edge, or data pattern
- Visual decode overlay for serial data streams
- Event tables show timestamped audio frames
- Adjustable sample width and bit alignment parameters
- Supports mono/stereo or multichannel TDM stream formats
- Easily export decoded audio values for logging or review
Applications
- Automotive AV bus testing and speaker/microphone routing
- Multichannel DSP or codec design
- Audio chip integration in smart devices
- Digital voice processing and filtering systems
- Technical training on digital audio fundamentals
Each Unit Includes
- 1 - Audio Serial Bus Trigger and Analysis Option (UPO7000L-AUDIO)
