PIE 520B-L Single Thermocouple Source Type L

Order # PIE 520B-L | Mfg # PIE 520B-L

PIE 520B-L Single Thermocouple Source Type L

$799.00

Ships in 3-4 weeks

The PIE 520B Thermocouple Simulator simulates a dedicated standard thermocouple curve over the entire industrial temperature range. It provides precise temperatures for inputs to all types of instruments such as transmitters, recorders, controllers, alarms, data acquisition, and computer systems. Choose your thermocouple type from the list below, or select the PIE 521B to simulate all 12 thermocouple types.

Tariff fees or manufacture imposed surcharges may be applicable.

Overview

Product Highlights:

Thermocouple Type: L
Accuracy ±(0.015% of mV Setting + 0.009mV)
Calibrate in temperature for your T/C type
Adjustable temperature output in selectable 0.1°C or 0.1°F steps
Typical accuracy of ±0.35°C (0.5°) for Type K
EZ-Dial™ knob easily adjust output by °C or °F with 0.1° resolution
Three position EZ-Check™ switch for 0% and 100% span adjustments
Uses standard "AA" Alkaline Batteries
Superior battery life of 45 hours under typical continuous usage
Easy access to battery compartment
Lightweight and Rugged with a Solid Feel
Small and tough Protected to 60V

Technical Resources

PIE Calibrators The Altek Replacements Datasheet
PIE Piecal 520B & 521B Thermocouple Source Datasheet
PIE Piecal 520B & 521B Thermocouple Source Operating Instructions
