| General |
Overall dimension |
236 mm x 167 mm x 70 mm (9.3 in. x 6.57 in. x 2.76 in.) |
| Weight |
1.68 kg (3.72 lb), including lithium-ion battery |
| Keypad |
English, Japanese, Chinese, International |
| Languages |
English, Spanish, French, German, Japanese, Chinese, Portuguese, Swedish, Norwegian, Dutch, Polish, Russian, Hungarian, Czech, Italian |
| Data storage |
Onboard and removable 2 GB MicroSD card |
| Battery life (Optional) |
16 h (lithium-ion) |
| Power requirements |
AC Mains: 100 VAC to120 VAC, 200 VAC to 240 VAC |
| Display type |
Full VGA (640 x 480 pixels) transflective color LCD |
| Display dimensions (W x H, Diag.) |
117 mm x 89 mm, 146 mm (4.62 in. x 3.49 in., 5.76 in.) |
| Min/Max capture mode |
Captured at 60 Hz measurement rate |
| Display update rate |
4, 8, 16 and 20 Hz |
| Alarm |
High and Low alarms |
| Resolution |
0.1 mm (0.01 in.), 0.01 mm (0.001 in.), 0.001 mm (0.0001 in.) (depending on thickness range) |
| Data logger |
Internal file-based alphanumeric data logger |
| Probes |
86PR-1 |
Standard straight probe 82.30 mm (3.24 in) long and 18.62 mm (0.733 in.) dia. |
| 86PR-2 |
Right angle probe head 58.84 mm x 18.62 mm, length 178.57 mm (2.32 in. x 0.733 in. dia.,length 7.030 in.) |
| 86PR-3 |
Low-profile articulating probe 241.3 mm (9.5 in.) long |
| Environmental Testing |
Vibration |
MIL-STD-810G, Method 514.6, Procedure I |
| Drop |
MIL-STD-810G, Method 516.6, Procedure IV |
| Shock |
MIL-STD-810G, Method 516.6 |
| Designed for IP67 |
Yes |
| Inputs/Outputs |
USB |
USB 2.0 peripheral port |
| RS-232 |
Yes |
| Memory card |
Maximum capacity: 2 GB removable MicroSD memory card |
| Video output |
VGA output standard |
| Foot switch (optional) |
Programmable (Save, Send, Meas or Q-Cal) |
| Operation temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
