MadgeTech VOLTX8-160MV
8-channel, DC voltage data logger with 160 mV range

Order #: VOLTX8-160MV

Mfg #: 902180-00

Questions about availability or need help? Contact Us:

(800) 633-0561
$1,049.00

MadgeTech VOLTX8-160MV

8-channel, DC voltage data logger with 160 mV range

Order #: VOLTX8-160MV

Mfg #: 902180-00

$1,049.00
Availability: Ships in 3-4 weeks
This product is available for shipping to the United States, Canada, and Puerto Rico only.
This product is available for shipping to the United States, Canada, and Puerto Rico only.
This product is available for shipping to the United States, Canada, and Puerto Rico only.

Product Highlights

8-channel, DC voltage data logger w/ 160 mV range

The VoltX Series includes 4, 8, 12, and 16-channel DC voltage data loggers. Includes standard calibration certificate.

  • Available in 3 Measurement Ranges
  • Memory Capacity of 2,700,000+ Readings
  • Accepts Signals from Common Voltage Sources

The VoltX Series includes 4, 8, 12 and 16-channel DC voltage data loggers and are available in three voltage ranges: 160 mV, 3.2 V, and 32 V.

The VoltX Series accepts voltage signals from sensors, transducers and many other common voltage sources. Capable of measuring and recording up to 2,794,836 readings, users have the option to enable or disable channels to maximize memory capacity. There's no interface necessary, the VoltX Series uses standard USB-A to Micro USB cable.

Using the MadgeTech Software, starting, stopping and downloading from the VoltX Series data loggers are simple and easy. Graphical, tabular and statistical data is provided for analysis and data can be viewed in multiple units, using the Engineering Units function. The data can also be automatically exported to Excel® for further calculations.

Win a Generac Generator when purchasing $750 or more from Transcat.Win a Generac Generator when purchasing $750 or more from Transcat.
Memory 4-channel: 698,709 readings per channel
8-channel: 349,354 readings per channel
12-channel: 232,903 readings per channel
16-channel: 174,677 readings per channel (all channels enabled)
Reading Rate 4 Hz up to 1 reading every 24 hours
Channels 4, 8, 12, 16
LEDs 1 per channel and 2 status LEDs
Battery Life 18 months
Material Black anodized aluminum
Dimensions 4-channel: 2.70 in x 7.25 in x 1.22 in (65.6 mm x 184.2 mm x 31.0 mm)
8-channel: 2.70 in x 7.25 in x 1.22 in(65.6 mm x 184.2 mm x 31.0 mm)
12-channel: 2.70 in x 7.25 in x 1.68 in(65.6 mm x 184.2 mm x 42.7 mm)
16-channel: 2.70 in x 7.25 in x 2.14 in(65.6 mm x 184.2 mm x 54.4 mm)
Operating Environment -20
