MadgeTech VOLT101A-15V Low Level, DC Voltage Recorder

Overview

Product Highlights

Low Level, -1 V to 16 V, DC Voltage Recorder

The Volt101A is a compact, low-level DC voltage data logger. Includes standard calibration certificate.

Compact Size
10-Year Battery Life
3 Measurement Ranges

The Volt101A is a compact, low-level DC voltage data logger. This device is available in four ranges: 2.5VDC, 15VDC, 30VDC and ±160mVDC.

With a user-programmable reading rate of up to 4 Hz, 10-year battery life and the ability to store up to 2,095,104 readings, the Volt101A is ideal for long-term studies. Connect negative and positive wire leads directly to the terminal block on the Volt101A to monitor and measure voltage levels. The terminal block easily disconnects to retrieve the logger for data download without disrupting wiring connectivity.

The Volt101A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

Technical Resources

Madgetech Volt101A Datasheet
Madgetech Volt101A Product User Guide

Specifications

Memory	2,095,104 readings
Reading Rate	4 readings every second up to 1 reading every 24 hours
Baud Rate	115,200
LED Indicators	Red & Green
Battery Life	10 years typical at a 15 minute reading rate
Material	Polycarbonate
Dimensions	1.4 in x 2.1 in x 0.6 in (35 mm x 54 mm x 15 mm)
Operating Environment	-40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	IFC200
Approvals	CE

Voltage Range	±160 mVDC, 0 to 2.5 VDC, 0 to 15 VDC, 0 to 30 VDC
Voltage Resolution	±160 mVDC: 5 ?V, 0 to 2.5 VDC: 0.1 mVDC, 0 to 15 VDC: 0.5 mVDC, 0 to 30 VDC: 1.0 mVDC
Voltage Calibrated Accuracy	±160 mVDC: ±0.01 %FSR @ 25 °C (77 °F), 0 to 2.5 VDC: ±0.05 %FSR @ 25 °C (77 °F), 0 to 15 VDC: ±0.05 %FSR @ 25 °C (77 °F), 0 to 30 VDC: ±0.05 %FSR @ 25 °C (77 °F)
