MadgeTech TEMP1000EX-1-KR

Product Highlights

ATEX/IECex Approved Temperature Data Logger w/ 1 inch probe and key ring end cap

The Temp1000Ex temperature data logger carries hazardous location certification (ATEX, IECEx). Includes ISO 17025 accredited calibration certificate.

• Compact Size
• ATEX Approved
• Available in a Variety of Probe Lengths

The Temp1000Ex is a compact, temperature data logger that carries hazardous location certification (ATEX, IECEx).

This one of a kind data logger is certified intrinsically safe for the following:

• Electrical Protection Concepts: ISO/IEC: 60079-11 Ex ia - Ex ic, Intrinsic Safety Zones 0-2
• Equipment Protection Level: Ga - Gc, Zones 0-2
• Gas Group: IIC
• Temperature Class: T4

The Temp1000Ex measures and records temperatures from -40 °C to +80 °C (-40 °F to +176 °F) with an accuracy of ±0.5 °C (0 °C to ±50 °C) and ±0.9 °F (32 °F to 122 °F). The Temp1000Ex can store up to 32,767 time and date stamped readings, and is available with either a flush bottom or key ring end cap.

The Temp1000Ex is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.
