Dwyer Instruments L6 Flotect Liquid Level Switch

Dwyer Instruments L6 Flotect Liquid Level Switch

Series L6 Flotect Liquid Level Switch

Order #: L6EP

Mfg #: L6EP

Questions about availability or need help? Contact Us:

(800) 633-0561 sales@transcat.com

$327.60

Qty

Product Overview

Product Highlights

The Series L6 Flotect® Level Switch is designed and built for years of trouble-free service in a wide variety of process liquid level applications. Operation is simple and dependable with no mechanical linkage as the level switch is magnetically actuated. The float lever pivoted within the body moves when the process liquid displaces the float. A magnet on the opposite end of the float lever controls a second magnet on the switch actuating lever located in the switch housing.

Features

Direct pump control for maintaining level
Automatic tank dump operations
Level control
Valve control
Level alarm in sumps, scrubber systems, hydro-pneumatic tanks, boilers, and water/wastewater treatment processes

Specifications

Service	Liquids compatible with wetted materials
Wetted Materials	Float: Solid polypropylene or 304 SS; Lower Body: Brass or 303 SS; Magnet: Ceramic; External Float Chamber (Tee): Matches lower body choice of brass or 303 SS; Other: Lever Arm, Spring, Pin, etc.: 301 SS
Temperature Limits	-4 to 220°F (-20 to 105°C) standard; MT high temperature option 400°F (205°C) (MT not UL, CSA, ATEX, IECEx and KC); ATEX compliant AT, IECEx IEC and KC option ambient temperature -4 to 167°F (-20 to 75°C) process temperature: -4 to 220°F (-20 to 105°C)
Pressure Limits	See model chart on Catalog Page
Enclosure Rating	Weatherproof and Explosion-proof. Listed with UL and CSA for Class I, Groups A, B, C and D; Class II, Groups E, F, and G. ATEX CE 0344 EX II 2 G EEx d IIC T6 Process Temp ≤ 75°C. EC-Type Certificate No: KEMA 04ATEX2128. ATEX Standards: EN 60079-0: 2009; EN60079-1: 2007. IECEx Certified: For Ex d IIC T6 Gb Process Temp = 75°C. IECEx Certificate of Conformity: IECEx DEK II.0039. IECEx Standards: IEC 60079-00: 2007; IEC 60079-1: 2007. Korean Certified (KC) for Ex d IIC T6 Gb Process Temp = 75°C. KTL Certificate Number: 2012-2454-75.
Switch Type	SPDT snap switch standard, DPDT snap switch optional
Electrical Rating	UL models: 5 A @ 125/250 VAC (V~). CSA, ATEX, and IECEx models: 5 A @ 125/250 VAC (V~); 5 A res., 3 A ind. @ 30 VDC (V~). MV option: .1 A @ 125 VAC (V~). MT option: 5 A @ 125/250 VAC (V~). [MT option not UL, CSA, ATEX, or IECEx]
Electrical Connections	UL models: 18 AWG, 18" (457.20 mm) long. ATEX/CSA/IECEx models: terminal block.
Upper Body	Brass or 303 SS
Conduit Connection	3/4" (19.05 mm) male NPT standard; 3/4" (19.05 mm) female NPT or M25 with BSPT option on junction box models
Process Connection	1" (25.40 mm) male NPT or 1" (25.40 mm) male BSPT on models without external float chamber; 1" (25.40 mm) female NPT or 1" (25.40 mm) female BSPT on models with external float chamber
Mounting Orientation	Horizontal with index arrow pointing down
Specific Gravity	See chart on Catalog page
Weight	Approximately 1 lb (.5 kg) without external float chamber; 1.75 lb (.8 kg) with external float chamber
Compliance	ATEX, CE, CSA, IECEx, KTL, UL
