Dionamix L-3520

Diode Array Detector wavelength range 190 nm to 640 nm

Order #: L-3520

Mfg #: 3021003520

Questions about availability or need help? Contact Us:

(800) 633-0561 sales@transcat.com

$15,995.00

Qty

Dionamix L-3520

Diode Array Detector wavelength range 190 nm to 640 nm

Order #: L-3520

Mfg #: 3021003520

New

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$15,995.00

Availability: Ships in 3-4 weeks

Ships Free Over $100

Available Promotions

This product is available for shipping to the United States, Canada, and Puerto Rico only.

Only need this item for a short time? Learn about rentals

Questions about this product? Speak to an expert

Product Overview

Product Highlights

The polychromatic light passing through the sample contained in the flow cell is absorbed by the compounds in the sample. The light output from the flow cell irradiates the diode array where the light intensity per nanometer wavelength is measured.

The L-3520 Diode Array Detector (DAD) responds to ultraviolet and visible light with wavelengths from 190nm to 640nm. The L-3520 uses a Deuterium light source, condenser and filter, flow cell, monochromator and 1024 Diode Array Detector with high sampling rates to achieve high sensitivity, low noise chromatograph spectrum.

Accessories

Dionamix 2010003743
C-type inlet check valve sleeve L-32XX Pumps

Order #: 2010003743

Mfg #: 2010003743

Availability: Ships in 3-4 weeks

$49.00

Qty

Specifications

	Specification
Detection Type	1024 Diode Array
Light Source	Deuterium Lamp
Wavelength Range	190nm to 640nm
Noise	±1.5 x 10^-5AU (JJG)	±0.6 x 10^-5AU (ASTM) at 254/4nm
Noise	Drift	0.5 x 10^-3 AU/Hr at 254/4nm
Absorbance Linear Range	>2.0 AU (5%) at 254nm
Wavelength Accuracy	±1nm
Spectral Resolution	0.6nm/pixel
Signal Data Sample Rate	12 Channel: 100 Hz	Full Spectrum: 100 Hz
Signal Data Sample Rate	Spectrum Data Sample Rate	Up to 100 Hz
Flow Cell	10mm Optical Path, 12 µL volume, 1200 psi maximum pressure
Control & Data Assessment	Dionamix Ultra	Chrom HPLC Workstation
Control & Data Assessment	Communication	LAN, USB Control Area Network (CAN)

	Specification
Weight	12.6 kg (27.8 lbs)
Dimension (LxWxH)	462 x 367 x 143 mm18.2 x 14.5 x 5.7 inches
Voltage	110 VAC rms - 240 VAC rms
Frequency	50 Hz - 60 Hz
Power	90 W max
Operating Temperature	5°C - 35°C (Temperature shift less than 2°C/hr)41°F - 95°F
Operating Humidity	20% RH - 80% RH
