Overview
Product Highlights
The CDI 8001-O-DTT Digital Torque Tester has a 1/4 Inch Drive and can test ranges an English range of 20-800 In Oz and Metric ranges between 14.1 - 565 cNm and 1.44 - 57.6 cmkg. The DTT Utilizing the testing protocol and standards developed by the American Society of Mechanical Engineers (ASME). The CDI Digital Torque Tester (DTT) is designed to be an affordable torque tester that can be mounted on a wall or used in a bench-top vise to allow the operator to conveniently test torque wrenches and torque screwdrivers. This digital torque wrench tester features an easy to use touch pad screen to capture peak torque values during a test in real time, and download stored torque data to a PC. All DTT torque testers are sold in a kit with the tester, carrying case and AC/DC power supply.
Integral Transducer and sturdy housing allow mounting in virtually any position
Integral Transducer: Full bridge strain gage, 350 ohm, 1500uE, 3mV/V F.S, 3.75 excitation.
Units of Torque: Nm, kgcm, ft.lb., in.lb., kgm
Audible (tone)
Torque Accuracy: ±0.5% CW and CCW from 5.6 to 100% of full scale at 25° C
± 1% CW & CCW from 2-1/2% to 100% of full scale. New for Torque Screwdrivers
LCD Touch Screen: 4.7 in. color graphics display
Screen resolution: 480 X 272 pixels
110 Volt AC/DC power supply included
Display Accuracy: 4 digits, 9999 cycle counts
Memory Capacity - 500 Records (Complete Check Mode Only.)
Data can be offloaded by USB drive or cable
Six "AA" Alkaline cells for battery power included
Track, Peak and First Peak modes of operation
Operating Temperature: 40 to 110° F (5 to 42° C)
Storage Temperature: 0 to 122° F (-20 to 50° C)
Humidity up to 85% non-condensing
ISO-6789-2003 and ASME B107-28-2005 standards compliant
Certificate of N.I.S.T. traceability from 5.6 to 100% of full scale
Includes storage case, AC adapter and USB cable
Dimensions: W - 10" x H - 16" x D - 2.5" Weight: (Tester Only) - 10.7 lbs., (with Carrying Case) - 17.4 lbs.
