The UNI-T MSO8000HDMD2G option dramatically expands MSO8000HD oscilloscope's memory depth capabilities, doubling the standard memory to 1 Gpts per channel in full-channel mode and 2 Gpts per channel in optimized dual-channel mode. This substantial memory increase enables capture and analysis of extended waveform sequences, long protocol communications, and complex system behaviors that require extended observation windows without sacrificing sample rate or timing resolution.
Essential for applications requiring analysis of lengthy digital communication sequences, system startup behaviors, or intermittent signal anomalies, the MSO8000HD-MD2G upgrade transforms the oscilloscope's capture capabilities while maintaining the industry-leading 20 GSa/s sample rate and 12-bit vertical resolution. This memory expansion is particularly valuable when combined with the MSO8000HD's advanced triggering and sequential capture modes.
- Doubles memory depth to 1 Gpts/CH (full channels) and 2 Gpts/CH
- Maintains full 20 GSa/s sample rate with extended memory depth
- Enhanced sequential mode supporting up to 520,000 segments
- Extended protocol analysis capabilities for complex communication sequences
- Deep memory correlation with advanced triggering and search functions
- Long-duration jitter and timing analysis with statistical confidence
- Comprehensive system startup and initialization sequence capture
- Extended eye diagram analysis with larger statistical datasets
- Enhanced compliance testing capabilities for lengthy test patterns
- Integration with all MSO8000HD analysis and measurement options
- Seamless compatibility with mixed-signal and protocol analysis functions
- Optimized memory management for efficient data processing and display
- Compatible Models: MSO8804HD, MSO8504HD
- Software license activation - no hardware modification required
- Dynamically allocated based on active channels and sample rate
- Extends digital channel memory to 125 Mpts
Applications
- Long-Duration Signal Capture
- Embedded System Analysis
- Protocol Debugging
- High-Speed Serial Bus Analysis
Each Unit Includes
- 1 - Memory Depth Upgrade Option (MSO8000HD-MD2G)
