The UNI-T MSO5000HDMANCH is a Manchester Wireless Communications Serial Bus Trigger and Analysis Option for MSO5000HD Oscilloscopes. The MSO5000HD-MANCH option unlocks decoding and triggering support for Manchester-encoded signals, which embed clock and data into a single self-synchronizing stream.
Manchester encoding is commonly used in RFID, IR communication, Ethernet (10BASE-T), magnetic stripe readers, and legacy bus systems. This decode license helps engineers easily visualize logic-level transitions, detect synchronization issues, and interpret data that would otherwise require a manual decode process.
- For use with MSO5000HD Oscilloscopes
- Decode standard Manchester-encoded bitstreams in real time
- Display bit-level and frame-level interpretation on waveform overlays
- Trigger on sync patterns, user-defined bit sequences, or errors
- Event table for browsing decoded bits and timing
- Support for both IEEE and G.E. Manchester polarity formats
- Capture and correlate analog anomalies like jitter, overshoot, or reflections
- Visualize Data and Timing in One View
- Faster Debugging of Legacy and Specialty Buses
- Polarity-Aware Triggering
Applications
- Aerospace & Defense
- Automotive
- Industrial Control
- Consumer Electronics
- RFID and Smart Cards
- Academic / Research
Each Unit Includes
- 1 - Manchester Wireless Communications Serial Bus Trigger and Analysis Option (MSO5000HD-MANCH)
