Simpson Electric 4006

Product Highlights

• Measure up to 1000V AC/ DC; up to 10A AC/DC
• True-RMS
• Resistance from 100m? to 60.00M?
• High capacitance measurement from 1pF to 40.00 mF with zero correction
• Frequencies from 10 Hz to 10 MHz
• Diode measurement and continuity testing
• Temperature measurement with K type thermocouple
• Peak value measurement; Hold, relative and duty cycle (%) measurement
• Backlit LCD, 4 digits/6600 count, Dual display for increased efficiency
• CAT III 1000V; CAT IV 600V
