Keysight Technologies DSOX1AUTO

Auto Serial Triggering&Analysis (CAN,LIN)for DSOX1000

Order #: DSOX1AUTO

Mfg #: DSOX1AUTO

Questions about availability or need help? Contact Us:

(800) 828-1470
$154.00

Keysight Technologies DSOX1AUTO

Auto Serial Triggering&Analysis (CAN,LIN)for DSOX1000

Order #: DSOX1AUTO

Mfg #: DSOX1AUTO

$154.00
Availability: Item ships in about Ships in 4-6 weeks
Available Promotions
This product is available for shipping to the United States and Canada only.
This product is available for shipping to the United States and Canada only.
This product is available for shipping to the United States and Canada only.

Only need this item for a short time? Learn about rentals

Questions about this product? Speak to an expert

Product Highlights

  • Decodes and analysis for CAN, LIN protocols
  • Compatible with DSOX1102A or DSOX1102G oscilloscopes
  • CAN
    • Trigger on CAN (controller area network) version 2.0A or 2.0B signals. Trigger on the start of frame (SOF), end of frame (EOF), data frame ID, data frame ID and data (non-FD), data frame ID and data (FD), remote frame ID, remote or data frame ID, error frame, acknowledge error, from error, stuff error, CRC error, spec error (ack or form or stuff or CRC), all errors, BRS bit (FD), CRC delimiter bit (FD), ESI bit active (FD), ESI bit passive (FD), overload frame, message, message and signal (non-FD), message and signal (FD, first 8 bytes only)
  • LIN
    • Trigger on LIN (Local Interconnect Network) sync break, sync frame ID or frame ID and data, parity error, checksum error and frame
