Fluke Calibration 1502A-2506 Thermometer Tweener with IEEE-488 110V, 59/60Hz
Thermometer Tweener w/IEEE-488 110V,59/60Hz
Order #: 1502A-2506
Mfg #: 4598226
$4,374.00
Fluke Calibration 1502A-2506 Thermometer Tweener with IEEE-488 110V, 59/60Hz
Thermometer Tweener w/IEEE-488 110V,59/60Hz
Order #: 1502A-2506
Mfg #: 4598226
$4,374.00
The Fluke 1502A Tweener features accuracy up to ±0.006 °C (the 1504 is even more accurate, up to ±0.002 °C). In addition, it reads 100-ohm, 25-ohm, and 10-ohm probes, has a resolution of 0.001 °C across its entire range, and is the smallest unit in its class. It also has an optional battery pack for completely portable operation.
Availability: Call for availability
Product Highlights
- Each Tweener is programmable to match a probe’s constants for maximum linearity and accuracy. All probe constants and coefficients are programmed through simple, front-panel keystrokes. Temperature is displayed in °C, °F, K, or resistance in ohms.
- The 1502A accurately measures the resistance of the probe and then converts the resistance to a temperature value using its built-in algorithms.
- For convenience, the 1502A reads the common industrial grade IEC-751 or “385 ALPHA RTD without any programming. Enter the actual R0 and ALPHA of the individual probe for increased accuracy. For maximum accuracy, use the ITS-90 formulas. The Tweener accepts the subranges 4 and 6 through 11.
- ITS-90 formulas reside in the Tweener’s firmware. If your probe has been calibrated for any of the above subranges of the ITS-90, you simply enter the coefficients directly into your Tweener.
- Each thermometer comes complete with an RS-232 interface for automation of temperature data collection, calibrations, or process control functions. An IEEE-488 interface is available as an option.
- The 1502A is calibrated digitally using the front-panel buttons. You never have to open the box to calibrate it. This calibration protocol further reduces the cost of the 1502A. It goes where you go and works the way you want it to.
