The EA-10000 Series programmable DC power supplies bring a host of capabilities and efficiencies to your application. Active power factor correction minimizes waste drawn from your power grid. True autoranging allows the delivery of maximum power along a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.
The EA PS and PSI programmable power supplies range in power from 1500W devices up to 30kW in a single chassis and feature 5" TFT Gorilla® Glass touchscreen displays for intuitive control and test setup. The power supplies can be paralleled for up to 3.84MW in output power at up to 2000VDC. The PSI Series comes standard with a built-in function generator capable of creating arbitrary waveforms, included test routines for battery test, fuel cell simulation, PV solar array simulation with MPP tracking, and other enhanced capabilities over the PS Series
EA-PS-11000-30-3U Single Output Programmable DC Power Supply, 1000V/30A, 10000W, 3U Rack converts the energy from the grid into a regulated DC voltage with an efficiency of up to 96%. The DC voltage and current are directed by the application and the spectrum ranges in this single device. The DC supply operates as a flexible output stage with a constant power characteristic (auto-ranging) and a wide voltage, current and power range. To achieve higher power and current this unit is equipped with a master-slave bus. This enables up to 64 parallel connected devices to be combined into one system. Such a system works as a single unit and can use different power classes, only the voltage class must remain constant.
- Wide range input: 208 to 480 V, +10%, 3ph AC
- Active Power Factor Correction, typical 0.99
- Output power rating: 0 to 10000 W
- Output voltage: 0 to 1000 V
- Output current: 0 to 30 A
- Rack housing: 19 in. x 3U
- Digital regulation, high resolution with 16-bit ADC's and DAC's, selection of voltage regulation speed: Normal, Fast, Slow
- 5 in. Color TFT display with touch control and intuitive user interface
- Master-slave bus for parallel operation of up to 64 units of all power classes in 10000 Series Power Supplies
- Command languages and drivers: SCPI and ModBus, LabVIEW, IVI
Applications
- Automated Test Systems
- Battery and Energy Testing
- Research and Development (R&D)
- Industrial Manufacturing
Each Unit Includes
- DC Power Supply 10KW 1000V 30A (EA-PS-11000-30-3U)
- 2 - Remote sensing plugs
- 1 - 1.8 m (5.9 ft) USB cable
- 1 - Set of DC terminal covers
- 1 - Sense terminal cover
- 1 - AC Cable Strain Relief
- 1 x AC connector plug (clamp type)
- 1 - USB stick with documentation and software
