The EA-10000 Series programmable DC power supplies bring a host of capabilities and efficiencies to your application. Active power factor correction minimizes waste drawn from your power grid. True autoranging allows the delivery of maximum power along a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.
The EA PS and PSI programmable power supplies range in power from 1500W devices up to 30kW in a single chassis and feature 5" TFT Gorilla® Glass touchscreen displays for intuitive control and test setup. The power supplies can be paralleled for up to 3.84MW in output power at up to 2000VDC. The PSI Series comes standard with a built-in function generator capable of creating arbitrary waveforms, included test routines for battery test, fuel cell simulation, PV solar array simulation with MPP tracking, and other enhanced capabilities over the PS Series
EA-PS 10920-125 4U is a high-performance, 30 kW programmable DC power supply unit from the PS 10000 4U Series, designed for demanding industrial testing, research, and development applications such as high-voltage device testing and photovoltaic (PV) simulation. This benchtop/rack-mount power supply delivers precise and stable DC power with a wide output range (920V, 125A), supporting operation as both a programmable DC voltage/current source and an adjustable electronic DC load (sink). It offers four programmable operating modes: constant voltage (CV), constant current (CC), constant power (CP), and internal resistance regulation (CR). Standard features include remote control via built-in USB and Ethernet ports, a galvanically isolated analog interface (0-5V/0-10V), and support for optional digital interface modules.
- Wide range input, 208VAC - 480VAC +10 % 3ph
- Active power factor correction, typical 0.99
- Power range of 0 - 30000W
- Voltage rating range from 0 - 920VDC
- Current rating range from 0 - 40A
- Regulation mode CV, CC, CP with fast crossover
- Digital regulation, high resolution with 16bit ADCs and DACs, selection of speed: normal, fast, slow
- Color 5" TFT display with touch control and intuitive user interface
- Galvanically isolated Share-Bus for parallel operation of all power classes in the 10000 series
- Command languages and drivers: SCPI and ModBus, LabVIEW, IVI
Applications
- Automated Test Systems
- Battery and Energy Testing
- Research and Development (R&D)
- Industrial Manufacturing
Each Unit Includes
- DC Power Supply 30KW 900V 125A (EA-PS-10920-125-4U)
- 2 - Remote sensing plugs
- 1 - 1.8 m (5.9 ft) USB cable
- 1 - Set of DC terminal covers
- 1 - Sense terminal cover
- 1 - AC Cable Strain Relief
- 1 x AC connector plug (clamp type)
- 1 - USB stick with documentation and software
