The EA-10000 Series programmable DC power supplies bring a host of capabilities and efficiencies to your application. Active power factor correction minimizes waste drawn from your power grid. True autoranging allows the delivery of maximum power along a wider range of voltage and current values while a suite of optional control interfaces enables computer control in near any manufacturing environment.
The EA PS and PSI programmable power supplies range in power from 1500W devices up to 30kW in a single chassis and feature 5" TFT Gorilla® Glass touchscreen displays for intuitive control and test setup. The power supplies can be paralleled for up to 3.84MW in output power at up to 2000VDC. The PSI Series comes standard with a built-in function generator capable of creating arbitrary waveforms, included test routines for battery test, fuel cell simulation, PV solar array simulation with MPP tracking, and other enhanced capabilities over the PS Series
EA-PS 10080-340 3U is a high-performance programmable DC power supply from the EA Elektro Automatik PS 10000 Series, delivering up to 80V output voltage, 340A output current, and 10000W output power in a compact 3U form factor. Designed for demanding industrial and laboratory applications, it combines high efficiency (up to 94.5%) with advanced autoranging technology, enabling a wide operating range and reducing energy costs. This power supply features precise voltage and current regulation with load regulation of ?0.05% FS for CV and ?0.1% FS for CC, and ultra-low ripple of ?10mV rms and ?100mV pp. Built-in protections safeguard sensitive loads against overvoltage, overcurrent, and overheating.
- Wide range input, 208 V - 480 V +10 % 3ph AC
- Active Power-Factor-Correction, typical 0.99
- Power range from 0 - 5000W
- Voltage from 0 - 60VDC
- Current range from 0 - 510A
- Regulation mode CV, CC, CP, CR with fast crossover
- Digital regulation, high resolution with 16bit ADCs and DACs, control speed: normal, fast, slow
- Colour 5" TFT display with touch control and intuitive user interface
- Galvanically isolated share-bus for parallel operation of all power classes in the 10000 series
- Command languages and drivers: SCPI and Modbus, LabVIEW, IVI
Applications
- Automated Test Systems
- Battery and Energy Testing
- Research and Development (R&D)
- Industrial Manufacturing
Each Unit Includes
- DC Power Supply 10KW 80V 340A (EA-PS-10080-340-3U)
- 2 - Remote sensing plugs
- 1 - 1.8 m (5.9 ft) USB cable
- 1 - Set of DC terminal covers
- 1 - Sense terminal cover
- 1 - AC Cable Strain Relief
- 1 - USB stick with documentation and software
